275 GTB Competizione Speciale

Technical Specifications

The 275 GTB/LM's are powered by the type 213 engine, tuned to the same specifications as the 275 LM 290 - 302 bhp

The chassis is a special round tube, lightweight unit, built specially for the LMS's. The bodywork on these cars is much more streamlined than the standard 275's, with larger and taller rear fenders which look like the 250 GTO's. They have a beautiful tailored nose with a lovely hood blister. No bumpers, although there are air induction holes on the front below the driving lights.

These four or five very special cars have superlightweight alloy bodywork and are built to 7/8 scale of the standard 275's.

Engine	213
Type	front, longitudinal 60° V12
Bore/stroke	77 x 58.8 mm
Unitary displacement	273.81 cc
Total displacement	3285.72 cc

Compression ratio

9.2 : 1

Maximum power	206 kW (280 hp) at 7600 rpm
	239 hp 7000 - 77x58 - 3286 - 6507

Valve actuation	single overhead camshaft per bank
	two valves per cylinder
Fuel feed	three or six 40 Weber DCN/3 carburettors
	Weber 6*40 DCN3
	Weber 6*40 DCNG
	Weber 3*40 DCZ6
Ignition	single spark plug per cylinder, two coils
Lubrication	wet sump
Clutch	single-plate

Chassis

563

Frame	tubular steel
Front suspension	independent, unequal-length wishbones,
	coil springs over telescopic shock absorbers,
	anti-roll bar
Rear suspension	independent, unequal-length wishbones,
	coil springs over telescopic shock absorbers,
	anti-roll bar
Brakes	discs
Transmission	5-speed + reverse
Steering	worm and roller
Fuel tank	capacity 94 litres
Ttyres

Front		195 or 205 x 14
Rear		195 or 205 x 14

Borrani	RW 3847 - 6-1/2" x 14" 32
	RW 4039 7" x 14" 32
Compagnolo/starburst	6-1/2" x 14"

Bodywork

Type	two-seater berlinetta
Length	4325 mm
Width	1725 mm
Height	1245 mm
Wheelbase	2400 mm
Front track	1377 mm
Rear track	1393 mm
Kerb weight	1100 kg

Performance

Top speed

258 km/h

Total

4 or 5
