Technical Specifications |
Engine |
Type |
Front longitudinal 60° V12, |
| light alloy cylinder block and head | |
Timing gear |
2 valves per cylinder, |
| single overhead camshaft per cylinder bank | |
Bore and stroke |
88 x 68 mm |
Unitary and total displacement |
413.46 cc / 4962.96 cc |
Compression ratio |
8.5:1 |
Maximum power |
340 bhp at 6,000 rpm |
Transmission |
Multi-plate clutch, 4 speed-gearbox + reverse, |
| conventional differential | |
Chassis |
Elliptical section steel tubes |
Front suspension |
Independent, double wishbones, |
| transverse lower leaf spring | |
Rear suspension |
Live axle, longitudinal leaf springs |
Wheelbase, front and rear track |
2,800/1,325/1,320 mm |
Kerb weight |
1,150 kg |
Front tyres |
7.10-15 |
Fuel tank |
140 litres |
Top speed |
262 km/h |
Chassis |
Frame |
tubular steel |
Front suspension |
independent, unequal-length wishbones, coil springs, |
| telescopic shock absorbers | |
Rear suspension |
live axle, semi-elliptic springs, |
| large telescopic shock absorbers | |
Brakes |
drums |
Transmission |
4-speed + reverse |
Steering |
worm and sector |
Fuel tank |
capacity 100 litres |
Front tyres |
6.50 x 16 |
Rear tyres |
6.50 x 16 |
|
Type |
coupé, cabriolet, two-seater |
Length |
- |
Width |
- |
Height |
- |
Wheelbase |
2800 mm |
Front track |
1455 mm |
Rear track |
1450 mm |
Weight |
1200 kg (dry) |
|
Total |
5 |
