Technical Specifications |
Engine |
Front longitudinal 60° V12, |
| light alloy cylinder block and head | |
Timing gear |
2 valves per cylinder, |
| single overhead camshaft per cylinder bank | |
Bore and stroke |
77 x 71 mm |
Unitary and total displacement |
330.62/3,967.44 cc |
Compression ratio |
8.8:1 |
Maximum power |
300 bhp at 6,600 rpm |
Fuel feed |
3 Weber 40 DCZ 6 carbs |
Ignition |
single spark plug per cyclinder, 2 coils |
Transmission |
Dry, single-plate clutch, |
| 4-speed gearbox + overdrive + reverse, | |
| conventional differential | |
Chassis |
Elliptical section steel tubes |
Front suspension |
Independent, unequal-length wishbones, coil springs |
Rear suspension |
Live axle, semi-elliptic leaf springs |
Wheelbase, front and rear track |
2,650 / 1,397 / 1,389 mm |
Kerb weight |
1,380 kg |
Fuel tank |
90 litres |
Top Speed |
245km/h |
