Technical Specifications


Engine

Type

front, longitudinal 60° V12

Bore/stroke

81 x 71 mm

Unitary displacement

365.86 cc

Total displacement

4390.35 cc

Compression ratio

8.8 : 1

Maximum power

235 kW (320 hp) at 6600 rpm

Power per litre

73 hp/l

Maximum torque

-

Valve actuation

single overhead camshaft per bank,

two valves per cylinder

Fuel feed

three twin-choke Weber 40 DFI/5 carburettors

Ignition

single spark plug per cylinder, two coils

Lubrication

wet sump

Clutch

single-plate


Chassis

Type

571 (Prototype)

598 remaining 13

Frame

tubular steel

Front suspension

independent,

unequal-length wishbones,

coil springs,

telescopic shock absorbers,

anti-roll bar

Rear suspension

live axle,

radius arms,

semi-elliptic springs,

coil springs over telescopic shock absorbers

Brakes

discs

Transmission

5-speed + reverse

Steering

servo-assisted recirculating ball

Fuel tank

capacity 100 liType front, longitudinal 60° V12tres

Front tyres

205 x 15

Rear tyres

205 x 15


Bodywork

Type

two-seater spider

Length

4900 mm

Width

1780 mm

Height

1330 mm

Wheelbase

2650 mm

Front track

1405 mm

Rear track

1397 mm

Weight

1320 kg (dry)


Performance

Top speed

245 km/h

Acceleration

0-100 km/h



Total

14
