Technical Specifications

Engine

Engine

60° V12, front longitudinal,

light alloy cylinder block and head

Timing gear

2 valves per cylinder,

single overhead camshaft per cylinder bank

Bore and stroke

60 x 58.8 mm

Unitary and total displacement

166,25/1,995 cc

Compression ratio

10:1

Maximum power

140 bhp at 6,600 rpm

Transmission

Dry, single-plate clutch, 5-speed gearbox + reverse,

conventional differential

Chassis

Elliptical-section steel tubes

Front suspension

Independent with transverse leaf spring

and hydraulic dampers

Rear suspension

Live axle, semi-elliptic longitudinal leaf springs,

hydraulic dampers and anti-roll bar

Wheelbase, front and rear track

2,200 / 1,250/ 1,200 mm

Kerb weight

650 Kg

Fuel tank

90 litres

Top speed

170 km/h



Test Sheet


0014M 166 MM 60 x 58,8 1995 140 hp @ 6600

0064M 166 MM 60 x 58,8 1995 127 hp @ 7000

0300M 166 MM 60 x 58,8 1995 154 hp @ 7200

0308M 166 MM 60 x 58,8 1995 153 hp @ 7200



Coachwork

Series I

33

Touring Barchetta

25 024MB, 0002M, 0004M, 0006M, 0008M, 0010M,

0014M, 0016M, 0020M, 0022M, 0024M, 0028M,

0034M ,0036M, 0038M, 0040M, 0044M, 0046M,

0050M, 0052M, 0054M, 0056M, 0058M, 0064M, 0068M

Touring Berlinetta

5 0026M, 0042M, 0048M, 0060M, 0066M

Vignale Spyder

1 0072E

Vignale Berlinetta

1 0062M

Zagato Berlinetta

1 0018M

Cycle Wing Spyder

1 0012M


Series II

13

Ferrari Spyder

2 0264M, 0272M

Vignale Spyder

7 0262M, 0266M, 0278M, 0290M, 0314M, 0328M, 0342M

Vignale Berlinetta

3 0244M, 0300M, 0308M

Pinin Faraina Berlinetta

1 0346M


Total

46

Ferrari 166 MM Touring Barchetta s/n 0002M



Ferrari 166 MM Touring Barchetta s/n 0004M

Ferrari 166 MM Touring Barchetta s/n 0004M

Ferrari 166 MM Touring Barchetta s/n 024MB

Ferrari 166 MM Fontana Jet Coupe s/n 024MB

Ferrari 166 MM Touring Barchetta s/n 0006M

Ferrari 166 MM Touring Barchetta s/n 0006M

Ferrari 166 MM Touring Barchetta s/n 0008M

166 MM Touring Barchetta s/n 0008M

Ferrari 166 MM Barchetta Touring s/n 0010M

Ferrari 166 MM Touring barchetta s/n 0010M

Ferrari 166 Spider Corsa s/n 008I / 0012M

Ferrari 166 Spider Corsa s/n 008I / 0012M

Ferrari 166 MM Touring Barchetta s/n 0014M

166 MM Touring Barchetta s/n 0014M

Ferrari 166 MM Touring Barchetta s/n 0016M

89 - displayed at Buenos Aires Museum, ARG

Ferrari 410 Superamerica Coupé Pinin Farina Series III s/n 1015SA

Ferrari 166 MM Zagato Berlinetta s/n 0018M

rebuilt as Spyder

Ferrari 166 MM Zagato Spyder Corsa s/n 0018M - Antonio Stagnoli - dnf

Ferrari 166 MM Touring Barchetta s/n 0020M

Ferrari 166 MM Touring Barchetta s/n 0022M

Ferrari 166 MM Touring Barchetta s/n 0034M

Ferrari 166 MM Touring Barchetta s/n 0024M

Ferrari 166 MM Touring Barchetta s/n 0024M

Ferrari 166 MM Touring Berlinetta LM s/n 0026M

Ferrari 166 MM Touring Barchetta s/n 0028M
or
Cycle Wing Spyder

missing

Ferrari 166 MM Touring Barchetta s/n 0034M

166 MM Barchetta Touring s/n 0034M

Ferrari 166 MM Touring Barchetta s/n 0036M

Ferrari 166 MM Touring barchetta s/n 0036M

Ferrari 166 MM Barchetta Touring s/n 0038M

Ferrari 166 MM Touring Barchetta s/n 0040M

Ferrari 166 MM Berlinetta Touring s/n 0042M

Ferrari 166 MM Touring Barchetta s/n 0044M

Ferrari 166 MM Touring Barchetta s/n 0046M
"Modified by Zagato as Berlinetta"

66 - Darrell Westfaul, Tuscaloosa, AL, USA

Ferrari 166 MM Touring Berlinetta s/n 0048M

Ferrari 166 MM Touring Berlinetta s/n 0048M

Ferrari 166 MM s/n 0050M / 0308M

Ferrari 166 MM Touring Barchetta s/n 0328M / 0050M

166 MM Touring Barchetta s/n 0050M/0328M

Ferrari 166 MM Touring Barchetta s/n 0052M

Ferrarin 166 MM Touring Barchetta s/n 0054M

Ferrarin 166 MM Touring Barchetta s/n 0054M

Ferrari 166 MM Touring Barchetta s/n 0056M

Ferrari 166 MM Touring Barchetta s/n 0058M

166 MM Barchetta Touring s/n 0058M

Ferrari 166 MM Touring Berlinetta LM s/n 0060M

166 MM Touring Berlinetta LM s/n 0060M

Ferrari 166 MM Vignale Berlinetta s/n 0062M

Ferrari 166 MM Vignale Berlinetta s/n 0062M

Ferrari 166 MM Touring Barchetta s/n 0064M

Ferrari 166 MM Touring Berlinetta s/n 0066M

Ferrari 166 MM Touring Barchetta s/n 0068M

1950  Ferrari 166 MM Touring Barchetta  [Casella / Gilli (ITA)]

Ferrari 166 Export Vignale Spyder s/n 0072E

Ferrari 166 Export Campana Spyder Corsa s/n 0072E - Luigi Fagioli / Alberico Cacciari - dnf

Ferrari 166 MM/53 Vignale Berlinetta s/n 0244M

166MM/53 Vignale Coupe s/n 0244M

Ferrari 166 MM/53 Vignale Spyder s/n 0262M

rebodied by Abarth as Spyder

Ferrari 166 MM/53 Abarth Spider s/n 0262M

Ferrari 166 MM/53 Ferrari Spyder s/n 0264M

rebodied by Fantuzzi as Barchetta


Ferrari 166 MM/53 Ferrari Spyder s/n 0264M - rebodied Touring Barchetta style

Ferrari 166 MM/53 Autodromo Spider s/n 0272M

Ferrari 166 MM/53 Vignale Spyder s/n 0278M

Ferrari 166 MM/53 Vignale Spyder s/n 0290M

Ferrari 166 MM/53 Oblin Spider s/n 0300M

Ferrari 166 MM/53 Oblin Spider s/n 0300M


Ferrari 166 MM/53 Spider Vignale s/n 0314M

Ferrari 166 MM/53 Vignale Spyder s/n 0308M

Ferrari 166 MM/53 Vignale Spyder s/n 0308M

Ferrari 166 MM Touring Barchetta s/n 0328M/0050M

166 MM Touring Barchetta s/n 0050M/0328M

Ferrari 166 MM/53 Vignale Spider s/n 0342M

Ferrari 166 MM/53 PF Berlinetta s/n 0346M

1953 Ferari 166 MM/53 Berlinetta Pinin Farina # 0346M
