Technical Specifications


Engine

Type

 128F and 128E/63

Engine

Front longitudinal 60° V12,

 light alloy cylinder block and head

Timing gear

2 valves per cylinder, single overhead camshaft per

cylinder bank

Bore and stroke

73 x 58.8 mm

Unitary and total displacement

246.10/2,953.21 cc

Compression ratio

8.8:1

Maximum power

240 bhp at 7,000 rpm

Fuel feed

 3 twin choke Weber 40 DCL6 carbs

Ignition

 single spark plug per cyclinder, 2 coils

Transmission

Dry, single-plate clutch,

 4-speed gearbox + overdrive + reverse,

 conventional differential


Chassis

Chassis type

 508E

Chassis

Elliptical section steel tubes

Front suspension

Independent, unequal-length wishbones, coil springs

Rear suspension

Live axle, semi-elliptic leaf springs

Wheelbase, front and rear track

2,600 / 1,354 / 1,394 mm

Kerb weight

1,280 kg

Fuel tank

100 litres

Top Speed

 230km/h


Total

302
Previous page
Next page
Up

Ferrari 250 GTE s/n 2487GT

330 engine installed

Ferrari 250 GTE s/n 2493GT

with Drogo body from 0716TR

Ferrari 250 GTE with Drogo body s/n 2493

Ferrari 250 GTE s/n 2495GT

SWB Berlinetta Replica by Sauro

Ferrari 250 GTE s/n 2495GT / SWB Berlinetta Replica by Sauro

Ferrari 250 GTE s/n 2497GT

250 GTE 2+2 SI s/n 2397GT


Ferrari 250 GTE s/n 2503GT

Ferrari 250 GTE s/n 2507GT

Ferrari 250 GTE s/n 2509GT

Ferrari 250 GTE s/n 2511GT

Ferrari 250 GTE s/n 2513GT

250 GTE s/n 2513GT

Ferrari 250 GTE s/n 2515GT

Ferrari 250 GT PF Cabriolet SII s/n 2115GT

Ferrari 250 GTE s/n 2517GT

rebodied California style

Ferrari 250 GTE s/n 2523GT

.. - rebodied as 500 TRC, engine 128F

Ferrari 250 GT Drogo rebody, s/n 2423GT

Ferrari 250 GTE s/n 2525GT

Ferrari 250 GTE s/n 2527GT

Ferrari 250 GT PF Cabriolet, s/n 2327GT

Ferrari 250 GTE s/n 2529GT

Ferrari 250 GTE s/n 2531GT

Ferrari 250 GTE s/n 2539GT

Ferrari 250 GTE s/n 2541GT

Ferrari 250 GTE s/n 2543GT

Ferrari 250 GT SWB Berlinetta s/n 2443GT

Ferrari 250 GTE s/n 2545GT

Ferrari 250 GTE s/n 2547GT

.. - engine in 4183 (GTE)

Ferrari 250 GTE s/n 2553GT

Ferrari 250 GTE s/n 2555GT

Ferrari 250 GT SWB s/n 2455GT

Ferrari 250 GTE s/n 2557GT

Ferrari 250 GTE s/n 2357GT

Ferrari 250 GTE s/n 2565GT

Ferrari 250 GT PF Cabriolet Series II s/n 2465GT

Ferrari 250 GTE s/n 2567GT

Ferrari 250 GT SWB California Spyder s/n 2467GT

Ferrari 250 GTE s/n 2569GT

Ferrari 250 GTE s/n 2571GT

Ferrari 250 GTE s/n 2573GT

.. - rebodied as 250 GT California Spyder Replica

Ferrari 250 GTE s/n 2575GT

Ferrari 250 GTE s/n 2577GT

Ferrari 250 GTE 2+2 s/n 2577GT

Ferrari 250 GTE s/n 2579GT

rebodied as 250/500 TR by DK Engineering

Terry Hoyle installed engine is 3675GT (250 GTE)

250 GTE 2+2 SI s/n 2379GT

Ferrari 250 GTE s/n 2581GT

Ferrari 250 GTE s/n 2583GT

Airfield Schleissheim 1962: The German amateur Lautenschlager at the wheel of his 250 GT California Spider Competizione s/n 2383GT

Ferrari 250 GTE s/n 2597GT

Reconfigured as ’59 250 TR
Engine from Lusso 5203GT

Ferrari 250 GTE s/n 2599GT

Ferrari 250 GT PF Cabriolet S2 s/n 2099GT

Ferrari 250 GTE s/n 2601GT



Ferrari 250 GTE s/n 2603GT

Ferrari 250 GTE s/n 2605GT

Ferrari 250 GTE s/n 2607GT

Ferrari 250 GTE s/n 2609GT

rebodied SWB Berlinetta style

Ferrari 250 GTE s/n 2615GT

Ferrari 250 GT PF Cabriolet SII s/n 2115GT

Ferrari 250 GTE s/n 2619GT

Ferrari 250 GTE s/n 2623GT

Ferrari 250 GT Drogo rebody, s/n 2423GT

Ferrari 250 GTE s/n 2625GT

Ferrari 250 GTE s/n 2627GT

Ferrari 250 GT PF Cabriolet, s/n 2327GT

Ferrari 250 GTE s/n 2633GT

Ferrari 250 GTE s/n 2635GT

Sidney, Australia - Miss Australia, Sabrina Houssami and the New Wales President celebrate Ferrari 60 Relay's passage - Ferrari 250 GT SWB Berlinetta s/n 2335GT

Ferrari 250 GTE s/n 2637GT

Ferrari 250 GT SWB California Spyder s/n 2537GT

Ferrari 250 GTE s/n 2641GT

.. - rebodied as ... TR by DK
.. - engine 2641 in 0977
