Technical Specifications

Engine

Type - Construction Number

110 Series I

111 Series II

Designer

Lampredi

Type

4-inline

Bore x Stroke

90.0 x 78.0

Displacement

1984cc

Compression Ratio

9.2:1

Camshaft Layout

Double overhead

Camshaft Drive

Gears

Cam Followers

Roller tappet

Valve Design

Inclined

No. of Valves

2 Values

Valve Springs

Hairpin

No. of Spark Plugs/Cylinder

2

Ignition

2 Magnetos

No. of Carburetors

2

Type of Carburetors

45 DCO/A3

40 DCO/A3

Bhp @ rpm

170 Bhp @ 7000rpm

Top speed

250 km/h


Drive Train

Clutch

Double dry plate

Transmission - No. of Gears

5-Speed & reverse

Transmission - Type

Non synchro

Transmission - Location

With rear axle Axle

Ration

3.92, 4.12, 4.34, 5.06:1


Chassis

Type

510

Chassis

Welded Tube

Frame

Ladder Type

Wheelbase

2250

Track Front

1278

Track Rear

1284

Suspension


Front

Independent

Type

Double wishbones

Springs

Transverse leaf - Series I

Coils - Series II

Suspension

Rear

De Doin

Springs

Transverse leaf

Shocks

Houdaille

Brakes

Drum

Wheels

Front

  Borrani

Rear

Borrani

Tires


Front

5.50 x 16

Rear

6.00 x 16


General

Body Designer

Dino Ferrari Farina

Body Builder

Scaglietti Pinin Farina

Length cm

Overall

Width
Height

Curb Weight kg

900



Test Sheet

0434

110 90x78 1985 160 hp 7000


Coachwork

Pinin Faraina Berlinetta

2 0422MD, 0452MD

Pinin Faraina Spyder

12 0404MD renumbered 0434MD, 0408MD, 0410MD,

0414MD, 0418MD, 0424MD/0564MD,0426MD,



0430MD, 0434MD, 0438MD, 0448MD, 0458MD

Scaglietti Spyder Series I

7 0406MD, 0446MD/0556MD, 0454MD, 0464MD,

0468MD, 0474MD, 0506MD

Scaglietti Spyder Series II

7 0512MD, 0528MD, 0536MD, 0556MD/0446MD,

0560MD, 0564MD/0424MD, 0580MD

Total

28


Monoposto

1 0574MD

Engine

1 0590MD



Total

30

Ferrari 500 Mondial PF Spyder s/n 0404MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0404MD

Ferrari 500 Mondial PF Spyder s/n 0406MD

rebodied Scgalietti style

Ferrari 500 Mondial Pinin Farina Spyder s/n 0408MD

Ferrari 500 Mondial Pinin Farina Spyder s/n 0410MD

Ferrari 500 Mondial PF Spyder s/n 0414MD

Ferrari 500 Mondial Spider Pinin Farina 0418MD

air intake on bonnet is a modification made in the 90's

Ferrari 500 Mondial PF Berlinetta s/n 0422MD


Ferrari 500 Mondial PF Spyder s/n 0424MD

renumbered
0564MD

Ferrari 500 Mondial PF Spyder s/n 0426MD

1954  Ferrari 500 Mondial Pinin Farina Spider, s/n 0426MD  [Lotti / Bruni (ITA)]

Ferrari 500 Mondial PF Spyder s/n 0430MD

Ferrari 500 Mondial Pinin Farina Spyder s/n 0434MD

500 Mondial Pinin Farina Spyder 0434MD

Ferrari 500 Mondial Pinin Farina Spyder s/n 0438MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0446MD

numbered 0556MD

Ferrari 500 Mondial PF Spyder s/n 0448MD

Ferrari 500 Mondial Pinin Farina Berlinetta s/n 0452MD

Ferrari 500 Mondial Pinin Farina Berlinetta s/n 0452MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0454MD

Ferrari 500 Mondial s/n 0454MD

Ferrari 500 Mondial Pinin Farina Spyder s/n 0458MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0464MD

Ferrari 500 Mondial s/n 0464MD - Siemes / Siemes (D)

Ferrari 500 Mondial Scaglietti Spyder s/n 0468MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0468MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0474MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0474MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0506MD

500 Mondial s/n 0506MD

Ferrari 500 Mondial Scaglietti Spyder Series II s/n 0512MD

rebodied as a Formula 2 single seater

Ferrari 625 F2, s/n 512MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0528MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0536MD

500 Mondial s/n 0536MD

Ferrari 500 Mondial Spyder Scaglietti s/n 0556MD

numbered
0446MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0560MD

Ferrari 500 Mondial Spider Scaglietti s/n 0560MD

Ferrari 750 Mondial Scaglietti s/n 0562M

rebuild with 500 Mondial engine

Ferrari 750 Mondial Scaglietti s/n 0562M

Ferrari 500 Mondial Scaglietti Spider s/n 0564/0424MD

renumbred
0424MD

Ferrari 500 Mondial Scaglietti Spider s/n 0564/0424MD

Ferrari 500 Mondial Monoposto s/n 0574MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0474MD

Ferrari 500 Mondial Scaglietti Spyder s/n 0580MD

Ferrari 500 Mondial s/n 0590MD

Engine only
