Technical Specifications |
The 250 Monza was powered by the V12 engine of the 250 MM, mounted in the chassis of the 750 Monza. |
|
Engine |
Engine |
Front longitudinal |
| 60° V12, light alloy cylinder block and head | |
Timing gear |
2 valves per cylinder, 1 overhead camshaft |
Bore and stroke |
73x 58.8 mm |
Unitary and total displacement |
246.16/2,953.2 cc |
Compression ratio |
9:1 |
Maximum power |
240 bhp at 7,200 rpm; 81 bhp/litre |
Transmission |
Dry, single-plate clutch, |
| 4-speed gearbox + reverse, ZF limited-slip differential | |
Front suspension |
Independent, double wishbones, transverse lower leaf |
spring |
Kerb weight |
850 kg |
|
Total |
4 |
