Technical Specifications |
|
Type |
front, longitudinal 60° V12 |
Bore/stroke |
81 x 71 mm |
Unitary displacement |
365.86 cc |
Total displacement |
4390.35 cc |
Compression ratio |
8.8 : 1 |
Maximum power |
235 kW (320 hp) at 6600 rpm |
Power per litre |
73 hp/l |
Valve actuation |
single overhead camshaft per bank, |
| two valves per cylinder | |
Fuel feed |
three Weber 40 DFI/5 carburettors |
Ignition |
single spark plug per cylinder, two coils |
Lubrication |
wet sump |
Clutch |
single-plate |
|
Frame |
tubular steel |
Front suspension |
independent, unequal-length wishbones, |
| coil springs over telescopic shock absorbers, anti-roll bar | |
Rear suspension |
independent, unequal-length wishbones, |
| coil springs over telescopic shock absorbers, anti-roll bar | |
Brakes |
discs |
Transmission |
5-speed + reverse |
Steering |
worm and roller |
Fuel tank |
capacity 90 litres |
Front tyres |
205 x 14 |
Rear tyres |
205 x 14 |
Bodywork |
Type |
two-seater coupé |
Length |
4470 mm |
Width |
1670 mm |
Height |
1300 mm |
Wheelbase |
2400 mm |
Front track |
1401 mm |
Rear track |
1417 mm |
Weight |
1350 kg (dry) |
Performance |
Top speed |
250 km/h |
|
