Technical Specifications


Engine


Type

rear, longitudinal flat-12

Bore/stroke

78.5 x 51.5 mm

Unitary displacement

249.25 cc

Total displacement

2991.01 cc

Compression ratio

11,5:1

Maximum power

331 kW (450 hp) at 10.800 rpm

Power per litre

150 hp/l

Maximum torque

-

Valve actuation

twin overhead camshaft per bank, four valves per

cylinder

Fuel feed

Lucas indirect injection

Ignition

single spark plug per cylinder, electronic

Lubrication

dry sump

Clutch

multi-plate


Chassis

Frame

tubular steel

Front suspension

independent, unequal-length wishbones,

coil springs, telescopic shock

absorbers, anti-roll bar

Rear suspension

independent, unequal-length wishbones,

coil springs, telescopic shock absorbers, anti-roll bar

Brakes

discs

Transmission

5-speed + reverse

Steering

rack-and-pinion

Fuel tank

capacity 117 litres

Front tyres

9-22-13

Rear tyres

13-26-15


Bodywork

Type

two-seater spider

Length

3500 mm

Width

1880 mm

Height

956 mm

Wheelbase

2220 mm

Front track

1425 mm

Rear track

1400 mm

Weight

585 kg (with liquids)


Performance


Top speed

320 km/h


Total

12
 Previous page
 Next page
Up

Ferrari 312 P s/n 0874

destroyed

Ferrari 250 TR/60 s/n 0774TR

Ferrari 312 P/B s/n 0876

Ferrari 312 P/B s/n 0878

chassis renumbered s/n 0880

Ferrari 312 PB s/n 0880

312 PB s/n 0880

Ferrari 312 PB s/n 0882

chassis 0884 used for repair

Ferrari 312 PB s/n 0882

Ferrari 312 PB s/n 0884

chassis 0898 used for repair

Ferrari 312 PB s/n 0884

Ferrari 312 P/B s/n 0886

Ferrari 312 P/B s/n 0886

Ferrari 312 PB s/n 0888

Ferrari 312 PB s/n 0888

Ferrari 312 PB s/n 0890

Ferrari 312 PB s/n 0890

Ferrari 312 PB Spyder s/n 0892


Brian Redman and Arthuro Mezario driving a 312 P - s/n 0892

Ferrari 312 PB Spyder s/n 0894

Ferrari 312 PB s/n 0894

Ferrari 312 PB s/n 0896



Ferrari 312 PB s/n 0896

Ferrari 312 PB s/n 0898

chassis used for repair of 0884
